Terex Washing Systems FM 60 Hydro

The Terex Washing Systems FM 60 Hydro™ is a fully integrated sand processing plant that combines sand washing and sizing within a single compact structure. Featuring a dewatering cyclone and a flat bottom classifier, the plant efficiently produces two in-spec sand products from a single feed point.

Technical specification

Equipment

Washing & Classifying
Application

Quarrying & Demolition
Dewatering screen

2.4m x 1.2m
Hydrocyclone

500mm
Pump size

150mm x 125mm
Max. tonnage

60tph

Key features

Electronically controlled hydraulic classification system reliably extracts light or small particles from slurry at high efficiency, whilst displacing a minimum of heavy or coarse particles to the overflow.
Direct bed level measurement allows maximum cut point control to produce up to two custom industrial or speciality sands from a single feed.
Multiple water injection nozzles result in uniform water distribution even at minimal flow rates.
The high frequency dewatering screen insures dry, immediately conveyable product for stockpiling.
